PELLET HOPPER HOUSING TEMPERATURE
Sensor Description Display
Thermostat with
automatic reset
Located on the pellet hopper, its function is to prevent excessive
temperature ranges.
WHEN ACTIVATED
If the pellet hopper temperature reaches critical levels, the thermostat
cuts off the power supply to the fuel-loading auger, thereby stopping the
supply of pellets to the grate and starting the stove shutdown process.
•The readout ‘ALC’ appears in the STOVE STATUS mode.
•After approx. 60 seconds the alarm sounds (if activated).
!
1
TANK TEMP
SAFETY
12:00 73F
WHAT TO DO
Shut down the stove by holding the ON/OFF key down for several seconds.
•The alarm will stop.
•Wait until combustion of any pellets remaining in the grate has nished.
•After having cleaned the grate, restart the stove by pressing the ON/
OFF key. (The readout TANK TEMP SAFETY must no longer appear on
the display. If this is not the case repeat the process described above.)
DT2010995-00
FLUE GAS TEMPERATURE SENSOR
Sensor Description Display
Smoke sensor
Connected to the electronic board, it constantly monitors the working
temperature allowing the stove to be used in all safety.
WHEN ACTIVATED
If the temperature exceeds the xed safety limit the board cuts off the
power supply to the fuelloading auger thus depriving the grate of pellets
and starting the stove shutdown process.
•In the upper part of the display appears the message “SAFETY” and in
the lover part appears “STOVE”.
•The readout ”MASS TEMP” and the ue gas temperature appear in the
STOVE STATUS mode.
•After approx. 60 seconds the alarm sounds (if activated).
!
12:00 73F
WHAT TO DO
•Shut down the stove by holding the ON/OFF key down for several seconds.
•The alarm stops.
•Wait until you are sure that combustion of any pellets remaining in the grate
has stopped.
•Check for and remove whatever has triggered the safety device.
•After having cleaned the grate restart the stove by pressing the ON/OFF key.
Smoke sensor
Disconnected
WHEN ACTIVATED
If the sensor is momentarily or accidentally removed from its normal
position, or is not connected properly to the electronic board, the readout
“NO CONN” and the ue gas temperature will appear in the STOVE STATUS
mode.
After approx. 60 seconds the alarm sounds (if activated).
