Technical details
Operating Manual PNOZ m B0
1002660-EN-07
33
Configurable inputs/outputs (inputs or auxiliary
outputs)
Configurable auxiliary outputs
Voltage 24 V
Output current 75 mA
Output current range 0 - 100 mA
Max. transient pulsed current 500 mA
Short circuit-proof yes
Residual current at "0" 0,5 mA
Voltage at "1" UB - 2 V at 0.1 A
Inputs
Number 12
Input voltage in accordance with EN 61131-2 Type 1 24 V DC
Input current at rated voltage 5 mA
Input current range 2,5 - 5,3 mA
Pulse suppression 0,5 ms
Maximum input delay 2 ms
Potential isolation No
Semiconductor outputs
Number of positive-switching single-pole semicon-
ductor outputs 4
Switching capability
Voltage 24 V
Current 2 A
Permitted current range 0,000 - 2,500 A
Residual current at "0" signal 0,05 mA
Max. transient pulsed current 12 A
Max. capacitive load 1 µF
Max. internal voltage drop 500 mV
Max. duration of off time during self test 330 µs
Switch-off delay 1 ms
Potential isolation yes
Short circuit-proof yes
Test pulse outputs
Number of test pulse outputs 4
Voltage 24 V
Current 0,1 A
Max. duration of off time during self test 5 ms
Short circuit-proof yes
Potential isolation No
Times
Simultaneity in the two-hand circuit 0,5 s
Processing time 30 ms
