Overview
Operating Manual PNOZ m B0
1002660-EN-07
7
2 Overview
2.1 Range
} Base unit PNOZ m B0
} Terminator
} Documentation on data medium
2.2 Unit features
Application of the product PNOZ m B0:
Base unit of the configurable control system PNOZmulti 2
The product has the following features:
} Can be configured in the PNOZmulti Configurator
} Semiconductor outputs:
4 safety outputs
Depending on the application, up to PL e of EN ISO 13849-1 and up to SIL CL 3 of EN
IEC 62061
} 12 inputs for connecting, for example:
– Emergency stop pushbutton
– Two-hand pushbuttons
– Safety gate limit switches
– Start button
– Light beam devices
– Scanner
– Enabling switch
– PSEN
– Operating mode selector switch
} 8 configurable inputs/outputs
Can be configured as:
– Inputs (see above for connection options)
or
– Auxiliary outputs
} 4 configurable outputs
Can be configured as:
– Auxiliary outputs
or
– Test pulse outputs
