Technical details
Operating Manual PNOZ m B0
1002660-EN-07
32
8 Technical details
General
Certifications CE, EAC (Eurasian), KOSHA, TÜV, cULus Listed
Application range Failsafe
Module's device code 0060h
Electrical data
Supply voltage
for Supply to the system
Voltage 24 V
Kind DC
Voltage tolerance -20 %/+25 %
Max. continuous current that the external power
supply must provide 1,6 A
Inrush current that the external power supply must
provide 3 A
Supply voltage
for Supply to the SC outputs
Voltage 24 V
Kind DC
Voltage tolerance -20 %/+25 %
Max. continuous current that the external power
supply must provide 8 A
Potential isolation yes
Supply voltage
Current consumption 32 mA
Power consumption 0,8 W
Max. power dissipation of module 7,4 W
Status indicator Display, LED
Permitted loads inductive, capacitive, resistive
Configurable inputs/outputs (inputs or auxiliary
outputs)
Number 8
Potential isolation No
Configurable inputs
Input voltage in accordance with EN 61131-2 Type
1 24 V
Input current at rated voltage 5 mA
Input current range 2,5 - 5,3 mA
Pulse suppression 0,5 ms
Maximum input delay 2 ms
