Operation
Operating Manual PNOZ m B0
1002660-EN-07
26
7.2 Display indicators
The LC display has four lines. It displays information and navigates the menu:
Display Example Description
RUN
State of inputs/outputs and
supply voltage
X3
X1
X2
X4
T
T
M
The lines are assigned ter-
minals X1 ... X4
Status:
Semiconductor output active
Semiconductor output inactive
Test pulse output
Message display (bottom right):
Message present
Error message present
Input active
Input inactive
ERROR
Status and error messages
Feedback
loop
Line 1 ... 4: Status and error
messages as short text.
DISPLAY MESSAGE
Display messages
E-STOP
pressed
Line 1 ... 4: Customised
messages that are created
in the PNOZmulti Configur-
ator.
PROJECT INFO
Project information
PNOZ m B0
project
CRC: 0x8108
20.04.2012
1st line: Project name
2nd line: Project name
3rd line: Check sum (CRC)
4th line: Creation date
SHOW DEVICE INFO?
Show device information
Show device
info?
Show device information for
the base unit and expansion
modules
DEVICE INFO
Device information for the
base unit and expansion
modules
Pos: 0
Version: 0000
PNOZ m B0
Firmw.: 0100
Pos: 0
H: 0
PNOZ m B0
1st line: Module position
(Pos)
2nd line: Product type
3rd line: Device version (Ver-
sion)
4th line: Firmware version
(Firmw.)
