Pilz PNOZ s4 User Manual

PNOZ s4
Operating Manual PNOZ s4
21396-EN-21
| 34
Mechanical data 751134 751184
Mounting position Any Any
Mechanical life 10,000,000 cycles 10,000,000 cycles
Material
Bottom PC PC
Front PC PC
Top PC PC
Connection type Spring-loaded terminal Spring-loaded terminal
Mounting type plug-in plug-in
Conductor cross section with
spring-loaded terminals: Flexible
with/without crimp connector 0,2 - 2,5 mm², 24 - 12 AWG 0,2 - 2,5 mm², 24 - 12 AWG
Spring-loaded terminals: Terminal
points per connection 2 2
Stripping length with spring-loaded
terminals 9 mm 9 mm
Dimensions
Height 100 mm 100 mm
Width 22,5 mm 22,5 mm
Depth 120 mm 120 mm
Weight 210 g 190 g
Where standards are undated, the 2022-09 latest editions shall apply.

Pilz PNOZ s4 Specifications

General

Safety category	4
Performance level	e
SIL CL	3
Supply voltage	24V DC
Number of safety contacts	3
Number of auxiliary contacts	1
Stop category	0 / 1
Width	45 mm
Depth	121 mm
Rated operational current Ie	6 A
Standards	EN ISO 13849-1, EN 62061
