OPERATING MANUAL PSEN op4F/H-A series

NOTE: The OSSDs are pulsed. The following diagram shows the time

characteristic of the OSSDs.

115 µs

500 ms

1000 ms

OSSD in safe state

OSSD2

OSSD1

24 V DC

GND

24 V DC

GND

Fig. 26 – Time characteristic of the OSSDs

1003067-EN-04
