OPERATING MANUAL PSEN op4F/H-A series
11 LIST OF AVAILABLE MODELS
Model
Protected
field height
(mm)
No. of
beams
Response time
AIC OFF
(ms)
Response time
AIC ON
(ms)
Resolution
(mm)
PSEN op4F-A-14-030/1
300
32
15
20
14
PSEN op4F-A-14-045/1
450
48
17
25
14
PSEN op4F-A-14-060/1 600 64 19 29 14
PSEN op4F-A-14-075/1
750
80
20
34
14
PSEN op4F-A-14-090/1
900
96
22
38
14
PSEN op4F-A-14-105/1
1050
112
24
43
14
PSEN op4F-A-14-120/1
1200
128
26
47
14
PSEN op4F-A-14-135/1
1350
144
27
52
14
PSEN op4F-A-14-150/1
1500
160
29
56
14
PSEN op4F-A-14-165/1 1650 176 31 61 14
PSEN op4F-A-14-180/1
1800
192
33
65
14
PSEN op4H-A-30-030/1
300
16
13
16
30
PSEN op4H-A-30-045/1 450 24 14 18 30
PSEN op4H-A-30-060/1
600
32
15
20
30
PSEN op4H-A-30-075/1
750
40
16
23
30
PSEN op4H-A-30-090/1
900
48
17
25
30
PSEN op4H-A-30-105/1
1050
56
18
27
30
PSEN op4H-A-30-120/1
1200
64
19
29
30
PSEN op4H-A-30-135/1
1350
72
19
32
30
PSEN op4H-A-30-150/1 1500 80 20 34 30
PSEN op4H-A-30-165/1
1650
88
21
36
30
PSEN op4H-A-30-180/1
1800
96
22
38
30
With the following formulas (and with reference to the response times stated in the tables below),
users can calculate the response time of any cascading configurations they create.
AIC OFF
(without code)
Tcascade [ms] = Tmaster + Tslave1 + Tslave2 + 7.5
AIC ON
(with code)
Tcascade [ms] = Tmaster AIC + Tslave1 AIC + Tslave2 AIC + 7.5
Response time of
Master AIC OFF
(ms)
Tmaster
Response time of
Slave AIC OFF
(ms)
Tslave
Response time of
Master AIC ON
(ms)
Tmaster AIC
Response time of
Slave AIC ON
(ms)
Tslave AIC
PSEN op4F-A-14-030/1
13.7
13.7
19.1
19.1
PSEN op4F-A-14-045/1
15.4 15.4 23.6 23.6
PSEN op4F-A-14-060/1
17.2 17.2 28.1 28.1
PSEN op4F-A-14-075/1
18.9
18.9
32.6
32.6
PSEN op4F-A-14-090/1
20.7
20.7
37.1
37.1
PSEN op4F-A-14-105/1
22.4
22.4
41.6
41.6
PSEN op4F-A-14-120/1
24.2
24.2
46.0
46
PSEN op4F-A-14-135/1
26.0 - 50.5 -
PSEN op4F-A-14-150/1
27.7 - 55.0 -
PSEN op4F-A-14-165/1
29.5
-
59.5
-
PSEN op4F-A-14-180/1
31.2
-
64.0
-
78
1003067-EN-04
