OPERATING MANUAL PSEN op4F/H-A series
10 TECHNICAL DETAILS
Electrical data
Operating voltage:
24 V DC ±20%
Current consumption transmitter (TX):
Max. 3 W
Current consumption receiver (RX):
5 W max (without load)
Outputs:
2 PNP or 2 NPN
- Short circuit protection:
1.4 A max
- Output current:
0.5 A max. at each output
- Output voltage – Status ON:
Operating voltage – 1 V min
- Output voltage – Status OFF:
0.2 V max.
- Capacitive load:
2.2 uF at 24 V DC max
Response times:
See table below
Reset time:
100 ms
Reset time when Sync interrupted:
2 Sec.
Height of protected field:
300..1800 mm
Category:
Type 4 (ref. to EN 61496-1)
SIL 3 (ref. to EN 61508)
SIL 3 (ref. to EN 62061)
PL e and Cat. 4 (ref. to EN ISO 13849-1:2008)
PFHd [1/h] = 2.64E-09
MTTFd [years] = 444
Auxiliary functions: Test; manual/
automatic restart; EDM; reset;
muting; blanking; GUI; coding; PNP/NPN
connection; cascading
Protection class:
Class III (see Ch. 4.1)
Current for external lamp:
20 mA min.; 300 mA max.
Connections: - M12 12-pin + M12 5-pin for receiver (muting
m
odel)
- M12 12-pin for receiver (blanking model)
- M12 5-pin for transmitter (for both models)
Cable length (for supply):
50 m max.
Optical data
Transmitter light (λ):
Infra-red, LED (950 nm)
Resolution:
14 - 30 mm
Operating range: 0.2…20 m for 30 mm
0.2…7 m for 14 mm
Ambient brightness:
IEC-61496-2
Environmental data and mechanical data
Operating temperature:
0…+ 50 °C
Storage temperature:
- 25…+ 70 °C
Temperature class:
T6
Humidity:
15…95 % (non-condensing)
Protection type:
IP 65 (EN 60529)
Vibration:
- Amplitude 0.35 mm,
- Frequency 10 … 55 Hz
- 20 sweeps per axis,
- 1 octave/min. (EN 60068-2-6)
Max. acceleration: 10 g
(EN 60068-2-29)
Housing material:
Varnished aluminium (yellow RAL 1003)
Front surface material:
PMMA
Terminator cap material:
PBT Valox 508 (RAL 7021)
Cover material:
PC LEXAN
Weight:
1.35 kg per running metre per individual unit
1003067-EN-04
77
