OPERATING MANUAL PSEN op4F/H-A series
BC
M configuration: Muting direction
PWR
OSSD
EDM
ACM
LEVEL
T (bidirectional) LED 6 ON green
L (one-directional) LED 6 OFF
AC
M configuration: Muting direction
1003067-EN-04
49
