OPERATING MANUAL PSEN op4F/H-A series
The existence of the tolerance is indicated by LEDs flashing on the user interface, as shown
below.
Tolerance display
PWR OSSD EDM ACM
LEVEL
Tolerance active LED 3 flashes yellow
The tolerance affects the light curtain's actual resolution. Make sure
that the new resolution is considered w
hen calculating a new
mechanical assembly.
Position tolerance
Dimension tolerance
1003067-EN-04
63
