First commissioning
Operating Manual PSEN sc B 5 Series
1004508-EN-02
50
3. Under Application, select EXPERT and 8-pin connection.
Configuration
You can enter a title for the configuration under Name.
You can enter the name of the person who created the configuration under Author.
You can describe the configuration in detail under Description.
The Configurator Version is entered by the system and cannot be changed.
The Check sum is entered by the system and cannot be changed.
The Creation date is entered by the system and cannot be changed.
Device
You can enter a title for the connected device under Name.
Click on the arrow
. The next window is opened: Output configuration. The number
of OSSD pairs is already selected.
4. Select Warning zone = 1.
If Warning zone = 1, the warning zone is activated. The output Pin 1 must be set to
WARNING1. The output is used as a warning output. Outputs Pin 5 and 6 are reserved
for OSSD1 and OSSD2 and cannot be changed.
Click on the arrow
. The next window Configure zone sets is opened.
5. Click on the arrow
. The next window Input configuration is opened
Zone set = 1 is already selected. Further settings are not required.
6. For Restart select the value Manual and define the Restart time (min. 80ms). Click on
the arrow
. The next window Configuration detection capability is opened
The wiring of inputs has already been configured by the previous selection.
7. Under Multiple evaluation, define the number of consecutive scans needed for detec-
tion.
Increasing the number of consecutive scans will increase the response time of the
safety laser scanner.
8. Select the detection capability [mm] for this safety laser scanner. Define the value for
Safety zone or for Warning zone.
9. Select Dust filter level (level1=low, level 3=high).
A higher level of dust filtering requires a longer safety distance.
