Operating Manual: PSS 3075-3 Series
4-3
INFORMATION
For further information on alarm processing please refer to the “FS System
Description” from the “PSS System Manual for the compact/modular PSS”
Outputs
Programmable safety systems from the PSS 3075-3 series have 18 single-
pole outputs (DOS) and 9 dual-pole outputs (DOZ). 4 of the single-pole
outputs can be configured as test pulse outputs (DOT).
INFORMATION
On programmable safety systems from the PSS 3075-3 series, only
outputs O1.16 ... O1.21, O/T2.0 ... O/T2.3, O2.8 ... O2.18, O4.0 ... O4.2
and O4.8 ... O4.10 are available at the terminals.
Please note: Unwired outputs O1.22 ... O1.31, O2.4 ... O2.7, O2.19 ...
O2.31, O4.3 ... O4.7 and O4.11 ... O4.15 cannot be configured in the
system software.
Single-pole outputs (DOT/DOS)
Programmable safety systems from the PSS 3075-3 series have 18 single-
pole outputs with a load capacity of 1.5 A.
The 4 outputs O/T2.0 ... O/T2.3 can be configured together as test pulse
outputs.
Outputs configured as test pulse outputs supply the test pulses to check
the input filters and optocouplers on the inputs. The CPU checks whether
the inputs connected to a test pulse output can detect a signal change.
INFORMATION
Please note that unused test pulses must remain unconnected.
