200
RS-232C Adjustment
Command Function
Number direct
Last
Effective Minimum Maximum
memory
WHITE BALANCE
RHI Adjusts R.HIGH of the white balance.  000 255 
GHI Adjusts G.HIGH of the white balance.  000 255 
BHI Adjusts B.HIGH of the white balance.  000 255 
GLW Adjusts G.LOW of the white balance.  000 255 
RLW Adjusts R.LOW of the white balance.  000 255 
BLW Adjusts B.LOW of the white balance.  000 255 
COLOR DETAIL
CGR Adjusts color detail red.  000 060 
CGY Adjusts color detail yellow.  000 060 
CGG Adjusts color detail green.  000 060 
CGC Adjusts color detail cyan.  000 060 
CGB Adjusts color detail blue.  000 060 
CGM Adjusts color detail magenta.  000 060 
GAMMA
GRAS18 Sets gradation GAMMA 1.8. 
GRAS19 Sets gradation GAMMA 1.9. 
GRAS20 Sets gradation GAMMA 2.0. 
GRAS21 Sets gradation GAMMA 2.1. 
GRAS22 Sets gradation GAMMA 2.2. 
GRAS23 Sets gradation GAMMA 2.3. 
GRAS24 Sets gradation GAMMA 2.4. 
PRESET
STD Restores the PICTURE, W/B adjustment value of the integrator to the initial values. 
7 “INTEGRATOR”–“SCREEN” related commands
Command Function
Number direct
Last
Effective Minimum Maximum
memory
POSITION
HPS Adjusts the horizontal position.  000 255 
VPS Adjusts the vertical position.  000 255 
CLOCK/PHASE
CFR Adjusts the CLOCK (PLL frequency).  000 255 
CPH Adjusts the PHASE (PLL phase).  000 031 
SIZE
HSI Adjusts the horizontal size.  000 064 
VSI Adjusts the vertical size.  000 064 
PRESET
FRP Restores the SCREEN adjustment value of the integrator to the initial values. 
7 “NTEGRATOR”–“SET UP” related commands
Command Function
Number direct
Last
Effective Minimum Maximum
memory
SUB VOLUME
SVL Adjusts the SUB VOLUME.  000 020 
