203
RS-232C Adjustment
Command Function
Number direct
Last
Effective Minimum Maximum
memory
DISPLAY CALL
DITS01 Displays DISPLAY CALL 1.
DITS02 Displays DISPLAY CALL 2.
IM0 INFORMATION write-in (1-3 characters).
IM1 INFORMATION write-in (4-6 characters).
IM2 INFORMATION write-in (7-9 characters).
IM3 INFORMATION write-in (10-12 characters).
IM4 INFORMATION write-in (13-15 characters).
IM5 INFORMATION write-in (16-18 characters).
IM6 INFORMATION write-in (19-21 characters).
IMD Clears INFORMATION.
AUXILIARY COMMAND
DW0 Subtracts 10 from the adjustment value.
DWF Minimizes the adjustment value.
DWn Subtracts n from the adjustment value. (n=1~9)
UP0 Adds 10 to the adjustment value.
UPF Maximizes the adjustment value.
UPn Adds n to the adjustment value (n = 1 to 9).
7 Other commands
5.5.6 QUEST Commands
What are QUEST commands?
• Quest commands output TXD such as adjustment data from the panel’s microprocessor to a PC.
• Adjustment and other data is output in ASCII code.
Note
Command names are given inside brackets < >.
• Data output format
Notes
• A QUEST command is invalid when no ID has not been assigned.
• A QUEST command is invalid when a wildcard (*) is used in the ID when sending the command.
STX (02hex)
Command
(3 Byte)
Data ···· Data
ETX (03hex)
Checksum
(2 Byte)
7 Quest Command Table
Command Function
QST Obtains status information.
QPI Obtains integrator/PICTURE information.
QWB Obtains integrator/WHITE BALANCE information.
QPS Obtains integrator/SCREEN information.
QSS Obtains SETUP information.
QSO Obtains Menu Integrator/OPTION information.
QSU Obtains audio status.
QCI Obtains time information.
QAP Obtains various machine names.
