Tilt Mount Unit: PDK-5011
4.6 Tilt Mount Unit: PDK-5011
4.6.1 Specifications
External dimensions ................. 1022 mm (W) × 610 mm (H) × 143 mm (D) (40-1/4 in. (W) × 24-1/32 in. (H) × 5-5/8 in. (D))
(mounting hardware and Plasma Display)
Weight ....................................... 13.8 kg (30.4 lbs.) (mounting hardware only)
44.3 kg (97.7 lbs.) (mounting hardware and Plasma Display)
Materials .................................... General structural steel tubes (STKM-R), SS400, SPHC
Finish.......................................... Semi-matte black paint on rear (Original Pioneer color)
Dimensions of packaging......... 890 (W) × 120 (H) × 700 (D) mm
(35-1/8 (W) × 4-23/32 (H) × 27-9/16 (D) in.)
Package weight......................... 18.0 kg
(39.7 lbs.)
Layers of packing ...................... 20 layers
Components
Tilt mount unit ..................................................... × 1
Bolt M8 ............................................................... × 6
Hexagonal wrench .............................................. × 1
For wall-mounting, allow adequate space (a clearance of 300 mm or more) above and below the panel, as well as on the
right and the left.
✩ Operating Temperature Restrictions
• Ambient temperature: 0 °C to 40 °C
✩ Operating Temperature Restrictions for Upside-Down Installations
* Upside-Down Installation is unavailable with the PDK-5011.
✩ Operating temperature restrictions for when the speaker system (PDP-S44-LR) is attached.
• Ambient temperature: 0 °C to 40 °C
