4.7 Wall Mount Unit: PDK-WM01
4.7.1 Specifications
External dimensions ...............1022 mm (W) × 610 mm (H) × 130 mm (D) (40-1/4 in. (W) × 24-1/32 in. (H) × 5-1/8 in. (D))
(mounting hardware and Plasma Display)
Weight .....................................9.3 kg (20.5 lbs.) (mounting hardware only)
39.8 kg (87.7 lbs.) (mounting hardware and Plasma Display)
Materials ..................................SPHC, SS400
Finish........................................Semi-matte black paint on rear (Original Pioneer color)
Dimensions of packaging.......1070 mm (W) × 100 mm (H) × 500 mm (D)
(42-1/4 (W) × 3-15/16 (H) × 19-11/16 (D) in.)
Package weight.......................11.5 kg
(25.4 lbs.)
Layers of packing ....................30 layers
Components
Wall mount unit ................................................... × 1
Tilt adjustment metal fitting ................................ × 1
Bolt M8 ............................................................... × 6
Hexagonal wrench
(Opposite side 6 mm for M8 use) ....................... × 1
Stencil ................................................................. × 1
In wall-mounting installation allow adequate space (a clearance of 300 mm or more) above and below the panel, as well
as on the right and the left.
✩ Operating Temperature Restrictions
• Ambient temperature: 0 °C to 40 °C
✩ Operating Temperature Restrictions for Upside-Down Installations
* Upside-Down Installation is unavailable with the PDK-WM01.
✩ Operating temperature restrictions for when the speaker system (PDP-S44-LR) is attached.
• Ambient temperature: 0 °C to 40 °C
✩ Attachment Restrictions
• Install it on perpendicular walls, columns, etc.
It cannot be installed on an inclined surface.
Wall Mount Unit: PDK-WM01
