PDP-436SXE
130
1234
1234
C
D
F
A
B
E
AV Block
7
1
Remove the two screws.
2
Disconnect cables, as required.
3
Remove the AV Block.
PDP-436SXE
only
PDP-436SXE
only
4
Disconnect the flexible cable.
5
Remove the two screws.
6
Remove the two screws.
7
Remove the R06 D-TUNER Assy.
AV Block
R06 D-TUNER
Assy
Terminal
support
1
5
66
5
5
4
1
3
7
OBE MAIN Assy
TUNER Assy
AUDIO Assy
R06 D-TUNER Assy
∗ Note: Be careful in handling the shielded flexible cable that
connects between the OBE MAIN and OB DIGITAL
Assys.
∗
PDP-436RXE
only
4
Remove the two screws.
5
Remove the terminal support.
4
4
436SXE model 436RXE model
To Next Page
