Pioneer PDP-6070PU User Manual

PDP-6071PU
109
5678
56
7
8
C
D
F
A
B
E
6. DISASSEMBLY
6.1 PCB LOCATION
SIDE KEY Assy
SIDE Assy
TANSHI
Assy
60 ADDRESS S
Assy
60 ADDRESS L
Assy
SP TERMINAL
Assy
60 Y DRIVE
Assy
60 X DRIVE
Assy
607 SCAN B Assy607 SCAN A Assy
AUDIO
Assy
MAIN
Assy
POD
Assy
60 DIGITAL
Assy
POWER SUPPLY
Unit
Rear view
60 ADDRESS S
Assy
60 ADDRESS S
Assy
60 ADDRESS S
Assy
PANEL SENSOR
Assy
60 ADDRESS L
Assy
60 ADDRESS L
Assy
60 ADDRESS L
Assy
60 IR Assy
42 & 60 LED
Assy
Front view Front view
