PDP-6071PU
183
5678
56
7
8
C
D
F
A
B
E
9.3.11 QMT
9.3.12 QNG
QMT : Returning information of temperature and FAN speed.
0 Received Command Name 3 byte ‘QMT’ only
1 MTB Temperature 3 byte
3 Cjheck Sum 2 byte
2 MTB FAN Speed 1 byte 0: STOP
1:LOW
2:HIGH
Order Data Size Context
Format
Effective Condition
Function
Remarks
[QMT] Every time
Output of status MTB-side's temperature/FAN rotaing status
QNG : Returning data (logs keep on Main microcomputer) on shutdown of Multi-Tuner Base.
0 Received Command Name on MTB 3 byte ‘QNG’ only
01 Latest NR data 1 byte
02 Data of subcategory for the latest NG 1 byte
03 Data of MTB hour meter for the latest NG 7 byte
04 Data of temperature for the latest NG 3 byte
05 2’st latest NG data 1 byte
06 Data of subcategory for the 2’st latest NG 1 byte
07 Data of MTB hourmeter for the 2’st latest NG 7 byte
08 Data of temperature for the 2’st latest NG 3 byte
:::
09 3rd latest NG data 1 byte
10 Data of subcategory for the 3rd latest NG 1 byte
11 Data of MTB hourmeter for the 3rd latest NG 7 byte
12 Data of temperature for the 3rd latest NG 3 byte
29 8’st latest NG data 1 byte
30 Data of subcategory for the 7’st latest NG 1 byte
31 Data of MTB hour meter for the 7’st latest NG 7 byte
32 Data of temperature for the 7’st latest NG 3 byte
Details of Data and subcategory
0 Normal
1 failure of communication to Module microcomputer MODULE (immediately Shutdown)
2 3-wire serial communication of Main microcomputer Go to subcategory ⇒ No.1
3 IIC communication failure of Main microcomputer & Unknown error Go to subcategory ⇒ No.2
4 communication failure of Main microcomputer MAIN (immediately Power Supply OFF)
5 FAN stopped FAN (immediately Power Supply OFF)
6 Abnormally high temperature at MTB.
failure of Digital Tuner
TEMP2 (After 30second warning, ture
Power Supply off)
7Go to subcategory ⇒ No.3
8 failure of Power Supply Go to subcategory ⇒ No.4
After 3 second warning, turn the Power
Supply OFF.
B Speaker short-circuit
0 Non subcategory
1 IF microcomputer communication failure IF (immediately Power Supply OFF)
2 MANTA communication failure (MULTI1) MULTI1 (immediately Power Supply
OFF)
4 MANTA communication failure (I/P) I/P
5 MANTA communication failure (D-SEL) D-SEL
Order Data Size Context
<SD Information No.>
Data Cause of shutdown Remarks
<No.1 Subcategory Information on "failure in 3-wire serial communication of Main microcomputer">
Data Cause of shutdown Remarks
Format
Effective Condition
Function
Remarks
[QNG] Every time
Output of status
To Next Page
