3. PCB PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560 Ω
47k Ω
0.5 Ω
1 Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k Ω RN1/4PC F562 x 10
1
5621
MarkNo. Description Part No.
LIST OF ASSEMBLIES
NSP 1..PANEL CHASSIS (607) ASSY AWU1178
NSP 2..60 ADDRESS ASSY AWV2363
NSP 3..60 ADDRESS L ASSY AWW1188
NSP 3..60 ADDRESS S ASSY AWW1189
NSP 2..60 SCAN ASSY AWV2364
3..607 SCAN A ASSY AWW1186
3..607 SCAN B ASSY AWW1187
1..60 X DRIVE ASSY AWV2366
1..60 Y DRIVE ASSY AWV2367
NSP 1..60 DIGITAL ASSY AWV2365
2..60 DIGITAL ASSY AWW1190
2..SENSOR ASSY AWW1191
1..MAIN ASSY (US BB) AWV2312
NSP 1..I/O ASSY AWV2313
2..POD ASSY AWW1154
2..TANSHI ASSY AWW1156
2..SIDE ASSY AWW1157
NSP 1..60 AUDIO FUKUGO ASSY AWV2347
2..AUDIO ASSY AWW1131
2..SP TERMINAL ASSY AWW1132
2..SIDE KEY ASSY AWW1133
2..42 & 60 LED ASSY AWW1134
2..60 IR ASSY AWW1137
> 1..POWER SUPPLY UNIT AXY1139
Mark No. Description Part No.
60 ADDRESS L ASSY
[60 ADR L LOGIC]
SEMICONDUCTORS
IC 1601 PEE003B
MISCELLANEOUS
L 1601 CHIP SOLID INDUCTOR QTL1013
CN 1601 PH CONNECTOR AKM1291
CN 1602 40P CONNECTOR AKM1348
RESISTORS
R 1601–1605 RS1/16SS1000F
Other Resistors RS1/16SS###J
CAPACITORS
C 1601–1604,1607 CKSSYF104Z16
C 1605,1606 CKSSYB102K50
C 1608,1609 CKSRYB105K6R3
C 1651–1656 ACG1105
C 1657–1662 CKSSYF104Z16
[60 ADR L RESONANCE]
SEMICONDUCTORS
IC 1720 TND307TD
Q 1710,1711 QSZ2
Q 1731,1741,1751,1761 HAT3041R
Q 1771,1781 HAT3041R
Q 1790 2SA1163
Q 1791 RN1901
D 1710,1737,1747,1757 1SS302
D 1731,1741,1751,1761 UDZS15(B)
D 1734,1744,1754,1764 EP05FA20
D 1736,1738,1746,1748 1SS355
D 1756,1758,1766,1768 1SS355
D 1767,1777,1787 1SS302
D 1771,1781 UDZS15(B)
D 1774,1784 EP05FA20
D 1776,1778,1786,1788 1SS355
MISCELLANEOUS
L 1730,1740,1750,1760 ATH1212
L 1770,1780 ATH1212
RESISTORS
R 1710,1711 RS1/16SS220J
Other Resistors RS1/16S###J
CAPACITORS
C 1710 CKSYB105K25
C 1711 ACG1098
C 1730,1740,1750,1760 ACG1137
C 1731,1741,1751,1761 ACG1136
C 1770,1780 ACG1137
C 1771,1781 ACG1136
60 ADDRESS S ASSY
[60 ADR S LOGIC]
SEMICONDUCTORS
Mark No. Description Part No.
