11.3 PANEL FACILITIES
Plasma Display
1 POWER
button
2
POWER ON indicator
3
STANDBY indicator
4
REC TIMER indicator
5
Remote control sensor
(Side view)
6 STANDBY/ON
button
7 INPUT
button (
ENTER
button*)
8 VOLUME UP/DOWN
buttons (
UP/DOWN
buttons*)
9 CHANNEL UP/DOWN
buttons (
LEFT/
RIGHT
buttons*)
10 TV GUIDE
button*
11
USB port
12
INPUT 4 terminals (COMPONENT VIDEO: Y,
C
B
/P
B
, C
R
/P
R
)
13
INPUT 4 terminal (VIDEO)
14
INPUT 4 terminals (AUDIO)
15
Stand: PDK-TS15 for the PDP-6072HD
PDK-TS15U for the PDP-6071HD/
PDP-6070HD
16
Speaker: PDP-S41
For details, refer to the operation manual that
came with the stand or speaker.
The buttons with asterisks (*) can operate the TV Guide On
Screen™ system.
ON REC TIMERSTANDBYPOWER
5
6
8
9
10
7
11
13
12
14
ON STANDBY REC TIMERPOWER
1
3
2
4
15 16
Front/side view
(PDP-6072HD/PDP-6071HD/PDP-6070HD)
