Pioneer PDP-6070PU User Manual

PDP-6071PU
177
5678
56
7
8
C
D
F
A
B
E
9.3.3 QIP
9.3.4 QAJ
Data Arrangement
Data
Length
Output Example
ECO 3 Byte QIP
1 SERIAL 15 Byte - - - - - - - - - - - - - - -
2 HOUR METER 8 Byte 00000000
3 TOTAL HOUR METER 8 Byte 00000000
4 PON COUNTER 8 Byte 00000000
5 TEMP1 acquisition (Temperature value) 5 Byte +23.5(*)
6 TEMP0 acquisition (Temperature value) 5 Byte +28.7(*)
7 MAX-TEMP1 acquisition (Temperature value) 5 Byte +78.3(*)
8 Reserved 4 Byte ∗∗∗∗
CS 2 Byte 94
Command
Format
Effective Operation
Modes
Function Remarks
[QIP] All operations To acquire data on operations of the panel Return data: 3 (ECO)+58(DATA)+2(CS)= 63 Byte
7 Acquisition of other data on the panel • • • [QIP]
The command QIP is for acquiring data on operational information of the panel.
(*) : Centigrade scale
Data Arrangement
Data
Length
Output Example
ECO 3 Byte QAJ
1 V-SUS adjustment value 3 Byte 128
2 V-OFT adjustment value 3 Byte 128
3 V-RST-P adjustment value 3 Byte 128
4 Reserved 3 Byte ∗∗∗
5 XSB adjustment value 3 Byte 128
6 YSB adjustment value 3 Byte 128
7 YTG adjustment value 3 Byte 128
11 RYW adjustment value 3 Byte 128
12 R-REVICE setting value 1 Byte 0
13 G-REVICE setting value 1 Byte 0
8 YTW adjustment value 3 Byte 128
9 RSW adjustment value 3 Byte 128
10 YTB adjustment value 3 Byte 128
14 B-REVICE setting value 1 Byte 0
CS 2 Byte B7
• For each REVICE setting value, the level set for RRL, RGL, or RBL is transmitted as one character.
Command
Format
Effective Operation
Modes
Function Remarks
[QAJ] All operations To acquire data on operations of the panel Return data: 3 (ECO)+41(DATA)+2(CS)= 46 Byte
7 Acquisition of panel adjustment data (common data) • • • [QAJ]
The command QAJ is for acquiring the panel's factory-preset data.
