(1) CHASSIS SECTION (2/2) PARTS LIST
(2) CONTRAST TABLE
PDP-6071PU/KUC, KUCXC, PDP-6070PU/KUC and KUCXC types are constructed the same except for the following:
Mark
No. Description Part No.
1 60 X DRIVE Assy AWV2366
2 60 Y DRIVE Assy AWV2367
3 60 DIGITAL Assy AWW1190
4PANEL SENSOR Assy AWW1191
> 5POWER SUPPLY Unit AXY1139
6Ferrite Core ATX1048
7 Flexible Cable (J201) ADD1453
8 Flexible Cable (J202) ADD1454
9 Flexible Cable (J203) ADD1455
10 Flexible Cable (J204) ADD1456
11 Flexible Cable (J205) ADD1457
12 Flexible Cable (J220) ADD1458
13 Flexible Cable (J221) ADD1459
14 Flexible Cable (J222) ADD1460
15 Flexible Cable (J223) ADD1461
16 Flexible Cable (J206) ADD1462
17 5P Housing Wire (J110) ADX3359
18 9P&7/6P Housing Wire (J102) ADX3406
19 8P&6P Housing Wire (J107) ADX3407
20 14P Housing Wire (J109) ADX3408
21
10P/5P Housing Wire (J104)(J127)
ADX3409
22
10P/5P Housing Wire (J114)(J128)
ADX3410
23 Housing Wire (J123) ADX3411
24 Conductive Plate X ANG2962
25 Nyron Rivet AEC1671
26 Wire Saddle AEC1745
27 Wire Saddle AEC1751
28 PCB Spacer AEC1819
29 Flat Clamp AEC1879
30 PCB Support AEC1938
31 Re-use PCB Spacer AEC1941
32 PCB Spacer AEC1947
33 Mini Clamp AEC1967
34 Harness Lifter 28 AEC1982
35 Ferrite Clamp AEC1986
36 Y Drive Protection Sheet A AMR3640
37 Rivet A BEC1158
38 • • • • •
39 • • • • •
40 • • • • •
41 Screw See Contrast table (2)
42 Screw ABA1364
43 Screw (M3 x 6) ABA1366
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-6071PU
/KUC
PDP-6071PU
/KUCXC
PDP-6070PU
/KUC
PDP-6070PU
/KUCXC
41 Screw ABA1351 ABA1313 ABA1351 ABA1313
