(1) MULTIBASE SECTION PARTS LIST
(2) CONTRAST TABLE
PDP-6071PU/KUC, KUCXC, PDP-6070PU/KUC and KUCXC types are constructed the same except for the following:
Mark
No. Description Part No.
1 MAIN Assy AWV2312
2TANSHI Assy AWW1156
3 POD Assy AWW1154
4AUDIO Assy AWW1131
5 SP TERMINAL Assy AWW1132
6Ferrite Core ATX1044
7Ferrite Core ATX1048
8Ferrite Core ATX1064
>
9Power Switch (S2)(TRAP) ASG1089
>
10 AC Inlet (CN1) AKP1300
11 Flexible Cable (J210) ADD1441
12 Flexible Cable (J211) ADD1442
13 Flexible Cable (J207) ADD1445
14 Flexible Cable (J213) See Contrast table (2)
15 Flexible Cable (J214)(J215) ADD1447
16 3P Housing Wire (J121) ADX3348
17 13P&11P Housing Wire (J119) ADX3402
18 3P Housing Wire (J112) ADX3469
19 11P Housing Wire (J105) ADX3360
20 7&6/4P Housing Wire (J111) ADX3405
21 Ferrite Core CTX1054
22 14P Housing Wire (J118) ADX3413
23 8/4P Housing Wire (J116) ADX3345
24 Binder AEC-093
25 Locking Card Spacer AEC1429
26 Wire Saddle AEC1745
27 Ferrite Core Holder AEC1818
28 Clamp AEC1884
29 Card Spacer AEC1889
30 Re-use Wire Saddle AEC1945
31 Ferrite Stopper AEC1981
32 Ferrite Clamp AEC1986
33 Locking Card Spacer AEC2019
34 6P Housing Wire (J113) ADX3404
35 POD Cover AMR3542
36 Multi Base (U) Assy ANA1951
37 Terminal Panel A (U/B) ANC2394
38 POD Stay A ANG2933
39 Tuner Stay U ANG3028
40 Gasket UI ANK1886
41 Gasket UD ANK1883
42 Gasket UA ANK1866
>
43 Gasket UB ANK1867
44 Locking Card Spacer AEC2093
45 • • • • •
46 Screw AMZ30P060FTB
47 Hex. Head Screw BBA1051
48 Nut BBN1005
49 Screw BMZ30P060FTB
50 Screw BPZ30P080FTB
51 Screw PMB30P080FNI
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-6071PU
/KUC
PDP-6071PU
/KUCXC
PDP-6070PU
/KUC
PDP-6070PU
/KUCXC
14 Flexible Cable (J213) ADD1470 ADD1446 ADD1470 ADD1446
