MAIN ASSY
[BOARD IF BLOCK(U)]
SEMICONDUCTORS
IC 4001–4005 TC74VCX541FT
Q 4001,4002 DTC124EUA
Q 4003 RN2902
Q 4004 DTA124EUA
MISCELLANEOUS
L 4001–4005 BTX1042
F 4001–4003,4011–4016 CTF1557
F 4005,4006 VTF1084
CN 4001,4004 AKM1349
CN 4005 AKM1348
CN 4006 KM200NA6
CN 4009 AKM1274
CN 4013 AKM1233
CN 4018 AKM1213
RESISTORS
R 4001RAB4CQ470J
R 4002,4018 RS1/16S102J
R 4012,4017,4048 RS1/16S75R0F
R 4016 RS1/16S0R0J
R 4021–4024 BCN1067
R 4073,4074 RS1/10S0R0J
Other Resistors RS1/16SS###J
CAPACITORS
C 4001–4003,4007,4027 CKSSYB104K10
C 4004 CCSSCH101J50
C 4006,4009,4010,4026 CCSSCH221J50
C 4011,4012,4017,4018 DCH1201
C 4013,4020,4021,4023 CKSSYB102K50
C 4014 CKSSYF104Z16
C 4016 ACG1128
C 4019,4022,4025,4030 CKSRYB102K50
C 4024 CKSSYB102K50
C 4033,4036,4039 CKSRYB102K50
C 4043 CKSSYB104K10
C 4051–4053 CCSSCH470J50
[POWER 0 BLOCK(U)]
SEMICONDUCTORS
IC 4101,4105 S-1132B18-U5
IC 4102,4103 LTC3412EFE
IC 4104,4111 NJM2846DL3-05
IC 4106 NJM2886DL3-15
IC 4107 NJM2846DL3-33
IC 4108 NJM2846DL3-18
IC 4110 PQ090DNA1ZPH
Q 4101,4110 RN1902
Q 4104 DTC124EUA
Q 4105,4106 UPA1917TE
Q 4107,4108,4112,4113 2SC4116
Q 4109 2SD2114K
D 4101–4110 1SS355
D 4111,4114,4115 1SS357
Mark No. Description Part No.
MISCELLANEOUS
L 4101 BTX1042
L 4102,4106 BTX1039
L 4108,4109 ATH1194
RESISTORS
R 4107,4110,4134–4136 RS1/10S0R0J
R 4119,4131,4146 RS1/16SS3003D
R 4120 RS1/16SS2003D
R 4123,4145 RS1/16SS1502F
R 4124 RS1/16SS6202D
R 4129 RS1/16SS3903D
R 4133 RS1/16SS1503D
R 4139 RS1/10S0R0J
R 4148 RS1/16S102J
Other Resistors RS1/16SS###J
CAPACITORS
C 4101,4103,4106,4108 CKSRYB105K10
C 4102,4104,4105,4107 DCH1201
C 4109,4111,4116,4119 DCH1201
C 4110,4117 CCSSCH101J50
C 4112 CCG1232
C 4113,4128 CKSSYB103K16
C 4114 BCG1050
C 4120,4121,4135,4156 CKSSYB104K10
C 4122 CCSSCH220J50
C 4124,4126 DCH1165
C 4125 CKSRYB104K16
C 4127 CKSRYB105K10
C 4129 CCSSCH390J50
C 4132,4133,4136,4137 BCG1059
C 4138,4140 CCSSCH221J50
C 4139 CCSRCH101J50
C 4142 BCG1059
C 4147 CCSRCH102J50
C 4165 DCH1201
C 4172 CKSSYB104K10
[ATUNER BLOCK(U)]
SEMICONDUCTORS
IC 4401 TC74HC4066AFT
IC 4402 AN5832SA
Q 4401,4416 DTC124EUA
Q 4402,4405,4409,4417 2SA1586
Q 4403 DTA124EUA
Q 4404,4406–4408,4410 2SC4116
Q 4411 2SC4116
Q 4413–4415 HN1B04FU
Q 4418 2SA1586
D 4401 1SS355
D 4402 UDZS30(B)
MISCELLANEOUS
L 4401–4405 BTH1121
F 4401–4404 VTF1080
K 4401,4402 AKX1061
>
U 4401 AXF116
>
U 4402 AXF117
Mark No. Description Part No.
