Pioneer PDP-6070PU User Manual

PDP-6071PU
37
5678
56
7
8
C
D
F
A
B
E
IC 3752 PQ120DNA1ZPH
IC 3753 NJW1183GK1
Q 3751,3754,3755,3757 2SA1586
Q 3756,3759 2SC4116
Q 3758,3760 DTC124EUA
D 3751 1SS355
MISCELLANEOUS
KN 3751,3752 WRAPPING TERMINAL VNF1084
CN 3751 CONNECTOR B3P-VH
3772,3773 PMB30P100FNI
3774,3775 VBB30P100FNI
RESISTORS
R 3803 RD1/2MMF2R2J
Other Resistors RS1/16S###J
CAPACITORS
C 3752,3753 CEHAT2R2M50
C 3754,3805 CFTLA103J50
C 3755 CEHAT472M25
C 3757 CEHAT471M25
C 3758,3760,3796 CKSRYB103K50
C 3759 CEHAT331M16
C 3761,3764,3786,3798 CEHAT101M16
C 3762 CEHAT220M50
C 3763 CEHATR47M50
C 3766,3780,3783–3785 CEHAT1R0M50
C 3767,3770,3781,3782 CFTLA104J50
C 3769,3815 CKSRYB222K50
C 3771–3774,3787,3789 CKSRYB224K16
C 3775,3777,3788,3790 CEHAT100M50
C 3778 CFTLA334J50
C 3779 CKSRYB822K50
C 3791,3799 CEHAT100M50
C 3792–3795,3806,3807 CFTLA104J50
C 3797,3808,3812,3814 CEHAT1R0M50
C 3800,3801 CKSRYB224K16
C 3811 CFTLA223J50
C 3813 CFTLA104J50
C 3816,3817 ACH1456
C 3818–3821 CCSRCH221J50
C 3822–3825 CKSRYB682K50
C 3826–3829 CKSRYF104Z50
>
C 3831,3833,3835,3837 CCSRCH101J50
C 3838,3839 CEHAT4R7M50
SP TERMINAL ASSY
MISCELLANEOUS
>
F 3901,3902 ATF1224
JA 3901 SPEAKER TERMINAL AKE1061
RESISTORS
>All Resistors RS1/16S###J
CAPACITORS
C 3903,3911,3917,3919 CKSRYB682K50
Mark No. Description Part No.
C 3904,3912,3918,3920 CKSRYF104Z50
>
C 3905,3907,3913,3915 CCSRCH221J50
>
C 3921–3924 CCSRCH221J50
SIDE KEY ASSY
MISCELLANEOUS
>
L 9501–9504 QTL1013
S 9501–9507 CSG1155
RESISTORS
All Resistors RS1/16S###J
CAPACITORS
C 9501 CKSRYF104Z16
C 9502,9503 CCSRCH101J50
42 & 60 LED ASSY
SEMICONDUCTORS
D 9601 SML-521MDW
D 9602 TLRV1022
D 9603 SML512BC4T
MISCELLANEOUS
CN 9601 CONNECTOR AKP1303
RESISTORS
All Resistors RS1/16S###J
CAPACITORS
C 9606,9610,9614 CKSSYF103Z50
C 9611 CKSRYF103Z50
60 IR ASSY
SEMICONDUCTORS
IC 9801 SBX3050-01
Q 9801 2SA1586
D 9801 1SS302
MISCELLANEOUS
CN 9801 CONNECTOR AKP1303
RESISTORS
R 9801–9803 RS1/16S0R0J
Other Resistors RS1/16SS###J
CAPACITORS
C 9801 CKSSYB102K50
C 9802 CKSSYF104Z16
C 9803 ACG7046
All Resistors RS1/16S###J
Mark No. Description Part No.
