Pioneer PDP-6070PU User Manual

PDP-6071PU
39
5678
56
7
8
C
D
F
A
B
E
RESISTORS
R 3611 RAB4C101J
Other Resistors RS1/16SS###J
CAPACITORS
C 3604-3606,3619 CKSSYB473K16
C 3609 CKSSYB104K10
[THERMAL SENSOR BLOCK]
CAPACITORS
C 3702 ACH1394
PANEL SENSOR ASS'Y
SEMICONDUCTORS
IC 3651 MM1522XU
IC 3652 BR24L02FJ-W
Q 3651 HN1B04FU
MISCELLANEOUS
CN 3651 PH CONNECTOR 6P AKM1276
RESISTORS
All Resistors RS1/16SS###J
CAPACITORS
C 3651,3653 CKSRYB105K6R3
C 3652,3654 CKSSYB103K16
C 3656,3657 CKSSYB104K10
60 X DRIVE ASSY
[X LOGIC BLOCK]
SEMICONDUCTORS
IC 1001 TC74ACT541FT
IC 1002 TC74ACT540FT
IC 1003 TC74VHC00FTS1
D 1001,1002 1SS355
MISCELLANEOUS
CN1001 40P CONNECTOR AKM1348
1001 BMZ30P080FTC
1001 ANH1639
1002 AEH1092
RESISTORS
R 1001,1003,1009 RAB4C470J
R 1005,1006,1011 RAB4C472J
VR1001,1002 CCP1390
Other Resistors RS1/16S###J
CAPACITORS
C 1001,1003 CEHAT470M16
C 1002,1004,1005 CKSRYB104K16
C 1006,1007 CCSRCH331J50
[X RESONANCE BLOCK]
Mark No. Description Part No.
SEMICONDUCTORS
IC 1101,1104 TND307TD
IC 1102 PS9117
IC 1103,1131 AXF1159
IC 1151 BA10393F
Q 1101 2SC2412K
Q 1102,1103,1131,1132 QSZ2
Q 1151 2SC4081
D 1101 UDZS5R6(B)
D 1106,1135 D1FL40
D 1112,1141 1SS302
MISCELLANEOUS
L 1101,1131 ATH1213
L 1102,1132 ATH1215
RESISTORS
R 1109,1118,1132,1141 RS1/10S2R2J
R 1112,1135 ACN1174
R 1114,1117,1137,1140 RS3LMF100J
R 1115,1116,1138,1139 RS1/10S104J
R 1121 RS1/16S3300F
R 1151,1154 RS1/10S1003F
R 1152,1155 RS1/16S5601F
R 1156,1157 RS1/16S6801F
Other Resistors RS1/16S###J
CAPACITORS
C 1101,1151,1153 CKSRYB104K16
C 1102,1113,1131,1143 CEHAT470M25
C 1103,1114 CKSRYF104Z50
C 1104,1117,1132,1144 CKSYB105K25
C 1106,1108,1135,1136 CCG1186
C 1115,1116,1141,1142 ACG1112
C 1118–1121,1156–1159 ACE1168
C 1154 CKSSYB104K10
C 1155 CKSRYB105K10
[X SUS BLOCK]
SEMICONDUCTORS
IC 1201,1206 PS9117
IC 1202,1207,1208,1210 TND307TD
IC 1203,1205 AXF1160
IC 1204 PQ05DZ11
IC 1209 TC7SH04FUS1
IC 1211 PQ09DZ11
Q 1201 2SC2412K
Q 1202,1205,1208,1209 QSZ2
Q 1203 HN1B04FU
Q 1204 DTC124EUA
Q 1206 2SC4081
Q 1207 R5009ANJ
Q 1251 DTC143EK
Q 1252 DTC123TKA
D 1201,1205 UDZS5R6(B)
D 1202,1203,1206,1210 CRH01
D 1204,1211 1SS355
D 1207 1SS302
D 1208 UDZS5R1(B)
D 1209 UDZS16(B)
Mark No. Description Part No.
