Pioneer PDP-6070PU User Manual

PDP-6071PU
41
5678
56
7
8
C
D
F
A
B
E
Q 2102,2103,2151,2152 QSZ2
Q 2181 2SC4081
D 2101 UDZS5R6(B)
D 2105,2154 D1FL40
D 2110,2159 1SS302
MISCELLANEOUS
L 2101,2151 ATH1213
L 2102,2152 ATH1215
RESISTORS
R 2109,2118,2152,2161 RS1/10S2R2J
R 2113,2156 ACN1174
R 2114,2115,2157,2158 RS3LMF100J
R 2116,2117,2159,2160 RS1/10S104J
R 2121 RS1/16S3300F
R 2181,2184 RS1/10S1003F
R 2182,2185 RS1/16S5601F
R 2186,2187 RS1/16S6801F
Other Resistors RS1/16S###J
CAPACITORS
C 2101,2181–2184 CKSRYB104K16
C 2102,2113,2162,2164 CEHAT470M25
C 2103,2114 CKSRYF104Z50
C 2104,2117,2151,2163 CKSYB105K25
C 2107,2108,2154,2155 CCG1186
C 2115,2116,2160,2161 ACG1112
C 2118–2121,2186–2189 ACE1168
C 2185 CKSRYB105K10
[Y SUS BLOCK]
SEMICONDUCTORS
IC 2202,2221,2232,2242 PS9117
IC 2203,2211,2222,2231 TND307TD
IC 2241,2252 TND307TD
IC 2251 TC7SH04FUS1
IC 2271 TND301S
IC 2301,2302 AXF1161
IC 2351 PQ05DZ11
IC 2380 PQ09DZ11
Q 2211 2SK3325
Q 2221,2232,2242,2243 QSZ2
Q 2222,2231,2241,2352 2SC4081
Q 2239,2271 2SK3050
Q 2240 2SC2412K
Q 2251 QSZ2
Q 2281-2283 2SK3399
Q 2290 DTC123TKA
Q 2291 DTC143EK
Q 2351 HN1B04FU
D 2208,2221,2231,2241 UDZS5R6(B)
D 2222,2223,2232,2233 CRH01
D 2242,2243,2281,2282 CRH01
D 2251 UDZS5R1(B)
D 2271 1SS301
D 2272 UDZS16(B)
D 2283,2289 UDZS9R1(B)
D 2290 UDZS8R2(B)
D 2351,2380 1SS355
Mark No. Description Part No.
MISCELLANEOUS
L 2351,2353,2354 BTH1134
L 2352,2355,2356 ATH1186
F 2301–2330 ATX1062
F 2351 CTF1449
K 2301,2351 AKX1061
KN 2202–2208,2301–2307 ANK1841
CN 2351 9P TOP POST B9B-EH
CN 2353 PH CONNECTOR 6P AKM1277
CN 2354,2356 PH CONNECTOR 10P AKM1281
RESISTORS
R 2202,2206 RS3LMF102J
R 2211,2214,2215 RS3LMF5R6J
R 2274,2275 RS3LMF561J
R 2287–2293 ACN1239
R 2301,2303,2307,2308 RS1/10S100J
R 2302,2304 RS1/10S0R0J
R 2305,2311 ACN1168
R 2351 ACN1162
Other Resistors RS1/16S###J
CAPACITORS
C 2211,2223,2233,2243 CEHAT470M25
C 2212,2272 CKSRYF104Z50
C 2221,2231,2241,2253 CKSYB105K25
C 2222,2232,2242,2290 CKSRYB104K16
C 2251 CCSRCH331J50
C 2252,2362 CKSRYB105K10
C 2256,2271,2291,2352 CEHAT470M25
C 2273,2281 CEHAT2R2M2E
C 2284,2286 ACE1163
C 2292 CKSYB105K25
C 2299 CKSRYB104K25
C 2301,2305 ACH1453
C 2302–2304,2306–2308 ACE1180
C 2309,2310 CCG1186
C 2351,2353,2361,2363 CEHAT470M16
C 2354,2359,2364,2380 CKSRYB104K16
C 2356,2357 ACH1449
C 2358 CEHAT101M10
C 2360 CKSRYB473K16
C 2367,2368 CEHAT101M25
C 2369 CEHAT470M16
C 2381 CKSRYB104K16
[Y SCAN BLOCK]
SEMICONDUCTORS
IC 2401,2403,2409 TLP116
IC 2402,2407,2421,2490 TC74AC540FT
IC 2405,2406,2408,2410 PS9117
IC 2481,2482 PST3638UR
MISCELLANEOUS
L 2401 BTH1136
L 2402,2403 BTH1134
F 2401,2402 ATX1062
CN 2401,2402 15P CONNECTOR AKM1200
Mark No. Description Part No.
