19
Installation Conditions
This unit is designed to be mounted using four bolt holes. For additional safety, we recommend securing it at four
points on opposite sides of the horizontal and vertical center lines, as shown in the drawing below.
Methods of securing
Secured at four points
(with mounting hardware attached to the top and
bottom)
*Attach using M8x4.
Secured at four points
(with mounting hardware attached to the sides)
*Attach using M8x4.
Take proper precautions to prevent pinching the power cord or signal cables.
