79
Before Beginning Adjustments
3 Integrator Mode
This mode provides an adjustment function for integrator options.
This mode has white-balance adjustment and various detailed settings in addition to the items in the menu mode.
For details, refer to section 5.4, “Integrator Mode” (pg. 142).
4 RS-232C Adjustment
In this mode, a personal computer is used to perform various adjustments and settings.
There are some items that can only be configured in this mode.
For details, refer to section 5.5, “RS-232C Adjustment” (pg. 189).
5.1.2 Combined Use of the Remote Control, Main-control Panel, and RS-232C Commands
• The remote control and main-control panel can be operated together.
(Example) It is possible to access the Menu Mode using the main-control panel then perform an adjustment
using the remote control.
• With the remote-control (or main-control panel) buttons and RS-232C commands, the most resent control has priority.
When connecting multiple sets and in this mode, assign an ID before making adjustments or settings.
Note
To Next Page
