25
Special Installation (Mounting to fittings)
35 mm or
less
Attach so that
the fan is on
the left side
when viewed
from the rear.
Example 1
Example 3
Example 4
Vertical installation
Standard installation
(In cases where top and bottom are reversed)
Example 2
35 mm or
less
35 mm or
less
35 mm or
less
