INSTALLATION OF ENGINE.
1. Attach a one-half ton (minimum) hoist to the engine hoisting straps and swing the engine into
alignment with its attaching points.
2. Insert an engine mount bolt, with washer against head, in the engine mount and slide half of the mount
assembly on the bolt. Repeat this procedure for the other three attachment points. (Refer to Figure 71-3.)
3. Position the mounting lugs of the engine so that they align with the engine mount attaching points,
then move the engine rearward onto the mounts.
4. Slide onto each mounting bolt a spacer washer, spacer and the forward half of the mount. Install
washer and nut, and torque the nuts of the bolts to 450 to 500 inch-pounds.
5. Connect the alternator leads and secure cable with clamps.
6. Connect the injector line to the flow divider.
7. Connect the manifold pressure line at the right rear side of the engine.
8. Connect the static and fuel flow line at the right rear engine baffle.
9. Connect the oil pressure line.
10. Install the line fitting in the vacuum pump and install lines.
11. Connect the tachometer drive cable.
12. Connect the oil temperature lead.
13. Connect the engine vent tube.
14. Connect the oil cooler.
15. Connect the magneto “P” leads. Check that magneto switch is “OFF.”
16. Connect the fuel pump supply and vent line.
17. Install the injector.
18. Connect the throttle and mixture cables to the injector. Check adjustment of the control.
19. Connect the heater hose to the muffler.
20. Install the air filter box, filter and box cover. Check adjustment of the alternate air door.
21. Connect the governor control cable and secure with clamps.
22. Connect the starter positive and ground leads and secure cables with clamps.
23. Secure the ignition harness, lines, hoses, wires, etc., that may be loose.
24. Install the propeller. (Refer to Chapter 61.)
25. Install the cowling by attaching the bottom cowl to the firewall and then installing the top. Connect the
electrical lead to the landing light.
26. Connect the gear door retraction rods and secure with bolts, washers and nut.
27. Install the proper grade and amount of engine oil. (Refer to Chapter 12 and to latest revision Lycoming
Service Instruction No. 1241.)
28. Turn on the fuel valve; open the throttle full and turn on the electric fuel pump. Check the fuel lines for
leaks.
29. Perform an engine operational check.
Effectivity 71-10-01
PA-28RT-201 Page 71-20
Revised: July 24, 1981
3C9
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL
