Introduction
Thank you for choosing a Pixsys controller.
With the ATR142 model Pixsys makes available in a single device all
the resources relevant to sensor input and actuators command, in
addition to the extended power range 24…230 Vac/Vdc. With 17
sensors to select and outputs configurable as relay or SSR command,
the user or retailer can reduce warehouse stock by rationalising
investment and device availability. The series is completed with
models equipped with serial communication RS485 Modbus. The
configuration is further simplified by the Memory cards which are
equipped with internal battery and therefore don’t require cabling to
power the controller.
2
Model Identification
The range of ATR142 controllers comes in two versions. Refer to the
table below to easily select your preferred model.
Models available, with power 24…230 Vac/Vdc +/-15% 50/60Hz – 3,5VA
ATR142-ABC
2 relays (8A+5A) + 1 Ssr
ATR142-ABC-T
1 relays 8A + 1 Ssr + Rs485
