11 Table of Configuration Parameters
The following table includes all parameters. Some of them will not be
visible on the models which are not provided with relevant hardware
features.
no. Display Parameter description Entering range
1
Command
Output
Select command output
type
Default
ATR142-ABC
COMMAND
ALARM 1 ALARM 2
Q2 Q1 SSR
Q1 Q2 SSR
SSR Q1 Q2
Q1(opens)
Q2(closes)
SSR -
ATR142-ABC-T
COMMAND
ALARM 1
Q1 SSR
SSR Q1
Q1(opens)
SSR(closes)
-
