Band Alarm (
selection
)
On
On
On
Off
Off
Off
Pv
Time
Alarm
output
Comand Spv
> 0
Hysteresis
parameter
Alarm Spv
Alarm Spv
Band alarm hysteresis value
greater than “0” (Par.28
> 0).
N.B.: The example refers to alarm 1;
the function can also be enabled for
alarms 2 and 3 on models that
include it.
On On
On
Off
Off
Off
Comand Spv
< 0
Hysteresis
parameter
Pv
Time
Alarm
output
Alarm Spv
< 0
Hysteresis
parameter
Band alarm hysteresis value
less than “0” (Par.28 <
0).
N.B.: The example refers to alarm 1;
the function can also be enabled for
alarms 2 and 3 on models that
include it.
