Pixsys ATR144 - GROUP I - d₁5 P. - Display and interface

70 - ATR144 - User manual
12.i GROUP I -
di s p.
- Display and interface
122 v .FLt Visualization Filter
dis a b. Disabled
ptcHf Pitchfork filter (Default)
fi. o r d . First Order
fi. o r. p. First Order with Pitchfork
2 s a.m. 2 Samples Mean
... ...n Samples Mean
10.sa.m. 10 Samples Mean
123 vi.d.2 Visualization Display 2
Selects visualization on display 2.
c.1.S P v Command 1 setpoint (Default)
o u. P e.1 Percentage of command output 1
rms.cu. RMS current (if the master function
CT 2000.35.014 is enabled).
124 tMo.d. Timeout Display
Determines the display timeout
diS a b. Disabled. Display always ON (Default)
1S S 15 seconds
1 Min 1 minute
5 Min 5 minutes
10 Min 10 minutes
30 Min 30 minutes
1 h 1 hour
125 tMo .S. Timeout Selection
Selects which display is switched off when Display
Timout expires
d is p. 1 Display 1
d is p. 2 Display 2 (Default)
d s p.1 . 2 Display 1 and 2
d.1.2.Ld. Display 1, 2 and led
