Signal Compatibility
66 EP Series Ultra HD LCD Displays User Guide
PC 1400x1050 49.965 54.113 100.000 x x x x VESA CVT
1400x1050 59.948 64.744 101.000 x x x x VESA CVT-R
1400x1050 59.978 65.317 121.750 x x x x VESA CVT
1400x1050 74.867 82.278 156.000 x x x x VESA CVT
1600x1200 60.000 75.000 162.000 x x x x VESA DMT
1920x1080 49.929 55.621 141.500 x x x x VESA CVT
1920x1080 59.963 67.158 173.000 x x x x VESA CVT
1920x1080 59.950 66.587 138.500 x x x x VESA CVT-R
1920x1200 49.932 61.816 158.250 x x x x VESA CVT
1920x1200 59.950 74.038 154.000 x x x x VESA CVT-R
1680x1050 49.974 54.121 119.500 x x x x VESA CVT
1680x1050 59.954 65.290 146.250 x x x x VESA CVT
1920x2160 60.000 135.000 297.000 x x x CEA-861-F, VIC 16, with vertical
parameters doubled
1920x2160 59.988 133.293 277.250 x x x VESA CVT-R
2560x1440 59.951 88.787 241.500 x x x VESA CVT-R
2560x1600 59.972 98.713 268.500 x x x VESA CVT-R
3840x2160 23.999 52.438 209.750 x x x VESA CVT-R
3840x2160 29.981 65.688 262.750 x x x VESA CVT-R
3840x2160 49.977 110.500 442.000 x x VESA CVT-R
3840x2160 59.997 133.313 533.250 x x VESA CVT-R
Apple
Mac
640x480 66.59 x x x x
832x624 75.087 49.107 55.000 x x x x
1024x768 59.278 48.193 64.000 x x x x
1024x768 74.927 60.241 80.000 x x x x
1152x870 75.062 68.681 100.000 x x x x
SDTV 480i 60 x x SMPTE 125M, CEA-861-F
Formats 6 &7
576i 50 x x ITU-R BT.601, CEA-861-F
Formats 21 & 22
EDTV 480p 60 31.469 27.000 x x x x ITU-R BT.1358, CEA-861-F
Format 17 & 18
576p 50 31.250 27.000 x x x x SMPTE 125M, CEA-861-F
Format 6 & 7
Signal
Type
Resolution
Frame rate
(Hz)
Line Rate
(kHz)
Pixel Rate
(MHz)
HDMI 3-4
& OPS
HDMI 1-2
DP1-2
VGA
References
