Planar EP5024K - Signal Compatibility

Signal Compatibility
EP Series Ultra HD LCD Displays User Guide 65
Signal Co mp atibility
Signal
Type
Resolution
Frame rate
(Hz)
Line Rate
(kHz)
Pixel Rate
(MHz)
HDMI 3-4
& OPS
HDMI 1-2
DP1-2
VGA
References
PC 640x480 59.940 31.469 25.175 x x x x VESA DMT, CEA-861-F Format 1
640x480 72.809 37.861 31.500 x x x x VESA DMT
640x480 75.000 37.500 31.500 x x x x VESA DMT
640x480 85.008 43.269 36.000 x x x x VESA DMT
800x600 60.317 37.879 40.000 x x x x VESA DMT
800x600 72.188 48.077 50.000 x x x x VESA DMT
800x600 75.000 46.875 49.500 x x x x VESA DMT
800x600 85.061 53.674 56.250 x x x x VESA DMT
848x480 59.659 29.830 31.500 x x x x VESA CVT
848x480 74.769 37.684 41.000 x x x x VESA CVT
848x480 84.751 42.969 46.750 x x x x VESA CVT
1024x768 60.004 48.363 65.000 x x x x VESA DMT
1024x768 70.069 56.476 75.000 x x x x VESA DMT
1024x768 75.029 60.023 78.750 x x x x VESA DMT
1024x768 84.997 68.677 94.500 x x x x VESA DMT
1152x864 70.012 63.851 94.500 x x x x VESA DMT
1152x864 75.000 67.500 108.000 x x x x VESA DMT
1152x864 84.999 77.094 121.500 x x x x VESA DMT
1280x768 49.929 39.593 65.250 x x x x VESA CVT
1280x768 59.995 47.396 68.250 x x x x VESA CVT-R
1280x768 59.870 47.776 79.500 x x x x VESA CVT
1280x768 74.893 60.289 102.250 x x x x VESA CVT
1280x768 84.837 68.633 117.500 x x x x VESA CVT
1280x960 60.000 60.000 108.000 x x x x VESA DMT
1280x960 75.000 75.000 126.000 x x x x VESA DMT
1280x960 85.002 85.938 148.500 x x x x VESA DMT
1280x1024 60.020 63.981 108.000 x x x x VESA DMT
1280x1024 75.025 79.976 135.000 x x x x VESA DMT
1280x1024 85.024 91.146 157.500 x x x x VESA DMT
1366x768 59.790 47.712 85.500 x x x x VESA DMT
