User’s Manual of IGS-5225 series
105
Buttons
: Send a test mail to mail server to check whether this account is available or not.
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.2.1.16 Fault Alarm
This page facilitates an update of the firmware controlling the switch. The Web Firmware Upgrade screen in Figure 4-2-19
appears.
Figure 4-2-19: Fault Alarm Control Configuration page Screenshot
The page includes the following fields:
Object Description
• Enable
Controls whether Fault Alarm is enabled on this switch.
• Record
Controls whether Record is sending System log or SNMP Trap or both.
• Action
Controls whether Port Fail or Power Fail or both for fault detecting.
• Power Alarm
Controls whether AC, DC1 or DC2 or both for fault detecting.
• Port Alarm
Controls which Ports or all for fault detecting.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
