User’s Manual of SGSD-1022 / SGSD-1022P
SGSW-2840 / SGSW-2840P
530
Command Mode
Interface Configuration (Ethernet)
Command Usage
Setting a lower value indicates a higher effective priority.
If an active port link goes down, the backup port with the highest priority is selected to replace the downed link. However, if
two or more ports have the same LACP port priority, the port with the lowest physical port number will be selected as the
backup port.
Once the remote side of a link has been established, LACP operational settings are already in use on that side.
Configuring LACP settings for the partner only applies to its administrative state, not its operational state, and will only
take effect the next time an aggregate link is established with the partner.
Example
Console(config)#interface ethernet 1/5
Console(config-if)#lacp actor port-priority 128
show lacp
This command displays LACP information.
Syntax
show lacp [port-channel] {counters | internal | neighbors | sysid}
port-channel -Local identifier for a link aggregation group. (Range: 1-12)
counters - Statistics for LACP protocol messages.
internal - Configuration settings and operational state for local side.
neighbors - Configuration settings and operational state for remote side.
sysid -Summary of system priority and MAC address for all channel groups.
Default Setting
Port Channel: all
Command Mode
Privileged Exec
Example
Console#show lacp 1 counters
Port channel : 1
Eth 1/ 1
