3
VLAN IEEE 802.1Q VLAN, up to 32 VLANs supported
QoS
IEEE 802.1p QoS support with 2 priority queue using WFQ (Weighted Fair
Queuing)
IGMP Multicast Filtering Passive snooping on IGMP Query/Report messages
Port trunking Up to 4 ports can be combined into a fat pipe
Port Mirroring 1 mirroring port to monitor several mirrored ports
Standards Conformance
Regulation Compliance FCC Part 15 Class A, CE
Standards Compliance
IEEE 802.3 (Ethernet)
IEEE 802.3u (Fast Ethernet),
IEEE 802.3z (1000Base-SX/LX), IEEE 802.3ab(1000Base-T),
IEEE 802.1D (STP),
IEEE 802.3x (full-duplex flow control),
IEEE 802.1p (QoS),
IEEE 802.1Q (VLANs)
RFC 768 UDP
RFC 783 TFTP
RFC 791 IP
RFC 792 ICMP
RFC 826 ARP
RFC 1122 Host Requirements
RFC 2068 HTTP
RFC 2236 IGMP v2
RFC 1157 SNMP v1/v2
RFC 1213 MIB II
RFC 1643 Ethernet MIB
