Planet vc-231 User Manual

12
30a prole
300m -> 100/100Mbps
400m -> 90/90Mbps
600m -> 61/40Mbps
800m -> 54/8Mbps
300m -> 100/100Mbps
400m -> 90/90Mbps
600m -> 69/55Mbps
800m -> 48/9Mbps
Power Requirement 5V DC, 2A
Dimension (W x D x H) 97 x 70 x 26 mm 155 x 86 x 26 mm
Weight 199g 368g
Operating Temperature 0~50ºC
Storage Temperature -25~70ºC
Operating Humidity 10% to 90%, relative humidity, non-condensing
Storage Humidity 10% to 90%, relative humidity, non-condensing
Switch Specication
Switch Processing
Scheme
Store-and-Forward
Address Table 1K entries 2K entries
Flow Control
Back pressure for half duplex
IEEE 802.3x Pause Frame for full duplex
Switch fabric 0.2Gbps 0.8Gbps
Throughput
(packet per second)
0.14Mpps 0.59Mpps
Network cables
10/100Base-TX:
2-Pair UTP Cat. 3,4, 5 (100meters, max.)
EIA / TIA-568 100-ohm STP (100meters, max.)
Standard Conformance
Regulation Compliance FCC Part 15 Class A, CE
Standards Compliance
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
ITU-T
● G.993.1 (VDSL)
● G.997.1
● G.993.2 VDSL2 (Prole 17a/30a)
* The performance data above is for reference only, the actual
data rate will vary on the quality of the copper wire and envi-
ronment factors.

Planet vc-231 Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1400 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Input current	2 A
Input voltage	5 V
Power consumption (typical)	6.6 W
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	97 mm
Height	26 mm
Weight	199 g
