5. Troubleshooting
SYMPTOM:
VDSL LNK LED does not light after wire is connected to the
VDSL port.
CHECKPOINT:
1. Verify the length of the wire connected between two VC-231
and VC-234 is not more than 1.4km. Please also try to adjust
the DIP switch or VC-231 / VC-234 to other SNR mode.
2. Please note you must use one VC-231 / VC-234 with CO
mode and the other VC-231 / VC-234 with CPE mode, connect
to each other to make it work.
SYMPTOM:
TP LED does not light after cable is connected to the port.
CHECKPOINT:
1. Verify you are using the Cat.5 or better cable with RJ-45
connector to connect to the port.
2. If your device (like LAN card) supports to Auto-Negotiation,
please try to manual set at a xed speed of your device to
solve this issue.
3. The Converter / Bridge and the connected device’s power are
on or not.
4. The port’s cable is rmly seated in its connectors in the switch
and in the associated device.
5. The connecting cable is good and with correct type.
6. The connecting device, including any network adapter is func
-
tional.

Planet vc-231 Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1400 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Input current	2 A
Input voltage	5 V
Power consumption (typical)	6.6 W
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	97 mm
Height	26 mm
Weight	199 g
