1.4 Specications
Product VC-231 VC-234
Hardware Specication
Ports
10/100Base-TX
1 RJ-45, Auto-negotiation
and Auto-MDI/MDI-X
4 RJ-45, Auto-negotiation
and Auto-MDI/MDI-X
VDSL 1 RJ-11, female Phone Jack
PHONE
Additional Splitter for
POTS connection
1 RJ-11, Built-in splitters
for POTS connection
DIP Switch &
Functionality
4 position DIP switch
•
CO / CPE mode select
• Selectable
fast and interleaved mode
• Selectable target
17a / 30a proles
• Selectable target
SNR mode
Encoding
• VDSL-DMT
- ITU-T G.993.1 VDSL
- ITU-T G.997.1
- ITU-T G.993.2 VDSL2 (Prole 17a/30a Support)
LED Indicators
•
One Power • One Power
• 3 for RJ-11/VDSL2: • 3 for RJ-11/VDSL2:
•
2 for per RJ-45
10/100Base-TX port
•
1 for per RJ-45
10/100Base-TX port
Cabling
Ethernet
• 10Base-T: 2-pair UTP Cat.3,4,5 up to 100m (328ft)
• 100Base-TX: 2-pair UTP Cat.5, up to 100m (328ft)
VDSL
Twisted-pair telephone wires (AWG24 or better) up
to 1.4km
Performance*
(Down Stream /
Up Stream)
17a prole
300m -> 86/65Mbps
400m -> 86/52Mbps
600m -> 81/36Mbps
800m -> 72/19Mbps
1000m -> 60/9Mbps
1200m -> 59/6Mbps
1400m -> 50/2Mbps
300m -> 99/70Mbps
400m -> 99/60Mbps
600m -> 90/45Mbps
800m -> 50/28Mbps
1000m -> 40/12Mbps
1200m -> 20/7Mbps
1400m -> 20/4Mbps

Planet vc-231 Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1400 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Input current	2 A
Input voltage	5 V
Power consumption (typical)	6.6 W
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	97 mm
Height	26 mm
Weight	199 g
