1. Introduction
1.1 Checklist
Check the contents of your package for following parts:
VC-231 / VC-234
Splitter (VC-231 only)
Power Adapter
RJ-11 Telephone Line
User’s Manual
If any of these pieces are missing or damaged, please contact
your dealer immediately, if possible, retain the carton including
the original packing material, and use them against to repack
the product in case there is a need to return it to us for repair.
1.2 Introduction to Ethernet over VDSL2 Bridge
PLANET’s state-of-the-art Ethernet-over-VDSL2 products are
based on two core networking technologies: Ethernet and
VDSL2 (Very-high-data-rate Digital Subscriber Line 2). This
technology offers the absolute fastest possible data transmission
speeds over existing copper telephone lines without the need for
rewiring.
The VC-231 / VC-234 Ethernet Over VDSL2 Converter / Bridge
has switching architecture with RJ-45 10/100Mbps Ethernet port
and one symmetric Ethernet over VDSL port (symmetry means
upstream and downstream rate are the same or similar) – the
VDSL port can be RJ-11 connectors. The VC-231 / VC-234 can
be set to CO mode or CPE mode via a DIP switch, when the
VC-231 / VC-234-CO is used to connect to the other VC-231 /
VC-234-CPE as a standalone pair, up to 100/100Mbps symmetric
data rate within 300m and up to 50/2Mbps asymmetric data
l
l
l
l
l

Planet vc-231 Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1400 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Input current	2 A
Input voltage	5 V
Power consumption (typical)	6.6 W
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	97 mm
Height	26 mm
Weight	199 g
