rate at 1.4km. This capability is ideal for use as an Ethernet
extender for your existing Ethernet network.
PLANET’s VDSL2 Converter solution provides a much cheaper
replacement and smooth migration for existing Long Reach
Ethernet (LRE) networks.
The cable specications of the connection are listed as following:
10Base-T, Category 3, 4 or 5 UTP
100Base-TX, Category 5 UTP
Ethernet over VDSL, Twisted-pair telephone wires
The two drawings listed below are typical application for the
Ethernet over VDSL2 Converter.
Note
Slave device (CPE) must connect to Master device
(CO) through the telephone wire. Slave cannot
connect to Slave and Master cannot connect to
Master. To define the VC-231 / VC-234 to CO or
CPE, please refer to section 2.2.1 for more detail.
l
l
l

Planet vc-231 Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1400 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Input current	2 A
Input voltage	5 V
Power consumption (typical)	6.6 W
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	97 mm
Height	26 mm
Weight	199 g
