Planet vc-231 User Manual

29
6. FAQ
Q1: What voltage that VC-231 / VC-234 used?
A1: 5V DC, 2A
Q2:
What is VDSL2?
A2: VDSL2 (Very High-Bit-Rate Digital Subscriber Line 2),
G.993.2 is the newest and most advanced standard of
xDSL broadband wire line communications.
Designed to support the wide deployment of Triple Play
services such as voice, data, high denition television
(HDTV) and interactive gaming, VDSL2 enable operators
and carrier to gradually, exibly, and cost efciently upgrade
exiting xDSL-infrastructure.
Q3: What is the best distance for VC-231 / VC-234?
A3: In order to guarantee the stability and better quality of
network, so we would suggest the distance in 1.4 kilometer
is the best for VC-231 / VC-234.
Q4: What is the best date rate for VC-231 / VC-234?
A4: We provide the data rate of the VC-231 / VC-234 is up
to 100Mbps/100Mbps (downstream / upstream) in 200
meters.
Q5: Can VC-201 compatible with VC-231 / VC-234?
A5: Currently NO. Although VC-201 (prole 12a) and VC-231
/ VC-234 (Prole 17a/30a) are base on ITU-T G.993.2
VDSL2, but with different Proles, so far they are not
compatible with each other.
Q6: What is SNR and what’s the effect?
A6: In analog and digital communications, Signal-to-Noise

Planet vc-231 Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1400 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Input current	2 A
Input voltage	5 V
Power consumption (typical)	6.6 W
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	97 mm
Height	26 mm
Weight	199 g
