Planet vc-231 User Manual

30
Ratio, often written SNR, is a measure of signal strength
relative to background noise. The ratio is usually measured
in decibels (dB).
In digital communications, the SNR will probably cause a
reduction in data speed because of frequent errors that
require the source (transmitting) computer or terminal to
resend some packets of data. SNR measures the quality of
a transmission channel over a network channel. The greater
the ratio, the easier it is to identify and subsequently isolate
and eliminate the source of noise.
Generally speaking, the higher SNR value gets better line
quality, but lower performance.
Q7: What is prole and what’s the benet?
A7: VDSL2 denes multiple band plans and conguration modes
(proles) to allow asymmetric and symmetric services in
the same binder (by designated frequency bands) for the
transmission of upstream and downstream signals. User
has the ability to select xed band plan. When 17a prole
is selected that provides long distance transmit with similar
performance, when 30a prole is selected that provides
short distance transmit with wire speed performance.

Planet vc-231 Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1400 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Input current	2 A
Input voltage	5 V
Power consumption (typical)	6.6 W
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	97 mm
Height	26 mm
Weight	199 g
