Planet vc-231 User Manual

20
3. Installing and Using VDSL Converter
3.1 Install the Ethernet Over VDSL2 Converter
The Ethernet over VDSL2 Converter / Bridge does not require
any software conguration. Users can immediately use any
feature of this product simply by attached the cables and plug
power on. There is some key limitation on the Ethernet over
VDSL2 Converter / Bridge. Please check the following items:
The device is used for Point-to-Point connection only (Master
device to Slave device) and allows data and voice work on
the same telephone lines.
VC-231 provides one RJ-11 connector for VDSL port and
the port can build VDSL2 connection easily. For voice device
connection, the additional splitter from VC-231 package is an
idea choice.
The VC-234 provides two RJ-11 connectors for VDSL port.
One for voice device connection (like telephone) and the other
one for network link connection.
Depending on the quality of telephone line, the maximum
distance of one VDSL segment is 1.4km (4593ft) with AWG
24 telephone wires. The distance could vary by the quality of
telephone wires or the installed environment.
l
l
l
l

Planet vc-231 Specifications

General

Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Converter input interface	100Base-TX
Maximum data transfer rate	100 Mbit/s
Fiber optic connector	-
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Wavelength	- nm
Maximum transfer distance	1400 m
Internal	No
Certification	FCC Part 15 Class A, CE
Product color	Black
Input current	2 A
Input voltage	5 V
Power consumption (typical)	6.6 W
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	97 mm
Height	26 mm
Weight	199 g
